Features



  1. Simple design allows for key or turn to throw or retract deadbolt in several combinations for all your locking needs
  2. Standard lock suitable for doors 32mm to 50mm thick. Extended cylinders available to accommodate thicker doors
  3. A threaded pin is used for secure cylinder retention



Specifications

Door Type

Timber or metal

Door thickness

32mm to 50mm standard. Extended cylinders available to accommodate thicker doors

Bolt

One piece sintered stainless steel

Lock case

Strike Plate

High purity zinc alloy

Satin stainless steel or brass

Backset

60mm

Key Cylinder

C4 6 pin keyway standard, Schlage C6 pin keyway optional, Schlage E6 pin keyway optional, Schlage Everest D keyway optional


Downloads

2022 Commercial Product Catalogue Legge 991MF Mortice Lock

Filename
2022 Commercial Product Catalogue Legge 991MF Mortice Lock.pdf
Size
792 KB
Format
application/pdf

Brochure Legge 990MF_995MF Series

Filename
1709 Brochure Legge 990MF_995MF Series.pdf
Size
2 MB
Format
application/pdf

Allegion Commercial Guide

Filename
2024 Allegion Commercial Guide.pdf
Size
4 MB
Format
application/pdf

Legge 991MF Mortice Lock Installation Instructions

Filename
Legge 991MF Mortice Lock Installation Instructions.pdf
Size
376 KB
Format
application/pdf

Lock Conversion Instructions Legge 990MF_990MFE Rebate Kit

Filename
1701 Lock Conversion Instructions Legge 990MF_990MFE Rebate Kit.pdf
Size
118 KB
Format
application/pdf

No selected resources found. Try another category.

Allegion Maintenance Guidelines

Filename
2024 AllegionAU Maintenance Guidelines.pdf
Size
265 KB
Format
application/pdf

Warranty Legge 990MF Series

Filename
1402 Warranty Legge 990MF Series.pdf
Size
85 KB
Format
application/pdf
