Legge 995 'C' Series Combination Entry Mortice Lock

Features

Designed to suit hollow stile metal door sections with internal depths from 39mm and narrow stile timber and french doors
The multi-function case allows easy conversion of a vestibule lock function (inside handle free) to a combination lock function (both handles locked) by a simple external operation
The reversible stainless steel latch adjusts for inwards/outwards opening and left/right hand without case disassembly
The latch is deadlatched by a stainless steel subbolt that retracts automatically with the main latch
The 995MF case will accept bolt-through fixing for 159mm vertical fixing door furniture such as the Legge 5300/5400 Series narrow stile furniture
Follower will accept 7.6mm-8mm furniture spindles, with no adjustment necessary

Door Type	Timber or Metal	Door Thickness	Timber doors - 32mm to 48mm standard. Extended cylinders, spindles and strike plates are available. Metal doors - 35mm to 48mm standard. Designed to be used on hollow stile door sections, with a minimum internal depth of 39mm
Lock Case	High purity zinc alloy	Backset	23mm standard. 30mm and 38mm available
Key Cylinder	CC4 6 Pin keyway standard, Schlage C6 pin keyway optional, Schlage SR1 Restricted keyway optional, Schlage Everest Open & Restricted keyways optional	Strike Plate	Satin stainless steel or brass
