Part No. | FES20 | FES20M | |
FUNCTION | Mortise mount, Power To Lock/Power To Release Input Voltage: 12/24VDC | Mortise mount, Power To Lock/Power To Release Input Voltage: 12/24VDC | |
HOLDING STRENGTH | Up to 1000kg | Up to 1000kg | |
| VOLTAGE/CURRENT |
Dual Voltage 12VDC/200mA 24VDC/100mA |
Dual Voltage 12VDC/200mA 24VDC/100mA | |
| APPROVALS |
Up to 4-hour fire rated in accordance with AS 1905
| Up to 4-hour fire rated in accordance with AS 1905 | |
MONITORING
| Door Latch monitoring | Non monitored | |
| SIZE | L= 125 x W= 42 x D= 35mm | L= 125 x W= 42 x D= 35mm | |
| IP RATING | N/A | Weather resistant iP56 |
